CB Ferrari A185 machining center
CB Ferrari A185 machining center
ConGri Macchine Utensili offers a vertical CB Ferrari A185 machining center complete with accessories. Contact us for information.
Technical Datasheet
| YEAR | 3/2009 |
| X AXIS COURSE | mm. 1.450 |
| Y AXIS COURSE | mm. 520 |
| Z AXIS COURSE | mm. 420 |
| SPINDLE NOSE DISTANCE TABLE TOP | |
| SPINDLE AXIS COLUMN DISTANCE | |
| X-Y-Z RAPID FEEDS | |
| SPINDLE (ISO or other) | Continuous head with electrospindle type 13415 ISO V40 |
| SPINDLE MOTOR POWER KW | 24/35 Kw - 90/130 Nm |
| SPINDLE SPEED (Min. Max) | RPM 16.000 |
| TABLE SIZE | |
| MAX LOAD ALLOWED | |
| NUMBER OF TOOLS IN STOCK | 30 Pos. |
| MAX. TOOL DIAMETER | |
| MAX. TOOL LENGTH | |
| MAX. TOOL WEIGHT | |
| CHIP-TO-CHIP CHANGE TIME | |
| CONTROL | ELEXA E580HS |
| DIMENSIONS L P H | |
| WEIGHT | |
| ACCESSORIES | |
| NOTES | Full CE-compliant fairing / Automatic door opening / Continuous head / 1-axis divider (A torque axis) type 043172 / Synchronized left divider type A043162 on motorized slide U = 800 mm. / Interpolator from SPLINE type E50010 / Fume extractor / Chip evacuation belt with auger / Mechanical tool calibration apparatus type 033800 / Blow-off system with external air type 050353. |
All technical data shown are indicative, may be changed without notice and refer to the standard condition of new goods. Used goods may not have the same performance as new.
