Edgewheel Grinder ER 13 N by Rosa Ermando

Rettifica tangenziale rosa ermando er 13 n
Rettifica tangenziale rosa ermando er 13 n
Rettifica tangenziale rosa ermando er 13 n
Rettifica tangenziale rosa ermando er 13 n

Edgewheel Grinder ER 13 N by Rosa Ermando

ConGri Macchine Utensili offers a used and overhauled Edgewheel Grinder ER 13 N by Rosa Ermando with warranty. Grinding mm.1.500×700.

Data Sheet



YEAR 1989
CODE
TECHNICAL DATA:
MAX GRINDING LENGTH mm. 1.500
MAX GRINDING WIDTH mm. 700
MAX GRINDING HEIGHT mm. 600
TABLE SIZE mm. 1.350 X 500
LONGITUDINAL SPEED OF THE TABLE m./min. 1-38
TRANSVERSAL SPEED OF THE TABLE m./min. 0-4
SNAP TRANSVERSAL SPEED
MAX ADMITTED LOAD Kg. 1.700
GRINDER:
GRINDING WHEEL SIZE mm. 400X100X127
GRINDING WHEEL SPEED Rpm./Min. 1.450
MOTOR POWER:
ENGINE OF MANDRIN THAT SUPPORTS THE GRINDER Kw. 8.8
ENGINE OF THE HYDRAULIC COMPONENTS Kw. 4
CONTROL UNIT ROSA SYSTEM N
MACHINE FOOTPRINT:
WEIGHT Kg. 8.500
OVERALL DIMENSIONS mm. 4.900 X 2.935 X 2.700
ACCESSORIES Electronic magnetic board 1.300x500x70

Purifier with paper filter

Bench diamond cutting with automatic compensation

Oil/air exchanger
NOTE Overhauled machine with warranty / A CE Compliant

All technical data are indicative, may be changed without notice and refer to the standard conditions of the new good. The second-hand good may not have the same performance as the new one.
