Favretto MD 300 Edge Wheel Grinding Machine
Favretto MD 300 Edge Wheel Grinding Machine
ConGri Macchine Utensili offers a Favretto edge wheel grinder model MD 300. Beautiful used CE certified machine with accessories.
Data sheet
| YEAR | 2011 |
| CODE | |
| TECHNICAL DATA: | |
| MAX GRINDING LENGTH | mm.3.200 |
| MAX GRINDING WIDTH | mm.900 |
| MAX GRINDING HEIGHT | mm.725 |
| TABLE SIZE | mm.3.220 |
| LONGITUDINAL SPEED OF THE TABLE | m./min. 1 - 40 |
| TRANSVERSAL SPEED OF THE TABLE | m./min. 5 |
| SNAP TRANSVERSAL SPEED | m./min. 1 - 50 |
| MAX ADMITTED LOAD | Kg. 4,000 Magnetic top excluded |
| GRINDER: | |
| GRINDING WHEEL SIZE | mm. 508 X 203,2 X 100 |
| GRINDING WHEEL SPEED | Giri/min. 1.400 |
| MOTOR POWER: | |
| ENGINE OF MANDRIN THAT SUPPORTS THE GRINDER | Kw. 22 |
| ENGINE OF THE HYDRAULIC COMPONENTS | |
| CONTROL UNIT | DTG PLUS |
| MACHINE FOOTPRINT: | |
| WEIGHT | Kg. 17.400 |
| OVERALL DIMENSIONS | mm. 9.450 X 3.645 X 2.955 |
| ACCESSORIES | Magnetic table top dimensions mm 3,200 X 600 / Coolant basin with paper filter / Diamond table top / |
| NOTE | USED / CE approved machine |
All technical data are indicative, may be changed without notice and refer to the standard conditions of the new good. The second-hand good may not have the same performance as the new one.
