Horizontal machining center Daewoo ACE-HP 500

ConGri Macchine Utensili offers a Daewoo ACE-HP 500 horizontal machining center. The machine has a few hours of work.

Technical datasheet

YEAR 2003
X AXIS COURSE mm. 800
Y AXIS COURSE mm. 700
Z AXIS COURSE mm. 750
SPINDLE ISO / 50
SPINDLE SPEED MIN./MAX rpm 8.000 Direct Drive
SPINDLE POWER IN KW/MAX 25 Kw.
OVERALL DIMENSIONS - MAXIMUM WORKPIECE Dia. mm. 800 X H. mm. 850
PALLET NUMBER 2
PALLET DIMENSIONS mm. 500 X mm. 500
B Axis 0,001°
MAXIMUM LOAD ALLOWED Kg. 500
RAPID FEEDS X,Y,Z
TOOL WAREHOUSE 40 positions
CONTROL Fanuc 18i-MB
OVERALL SIZE mm. 2.680 X 5.260 X 3.020
WEIGHT Kg. 12.500
ACCESSORIES Chip conveyor / Coolant tank with high pressure through spindle and paper filter / Spindle line cooler.

All technical data shown are indicative, may be changed without notice and refer to the standard condition of new goods. Used goods may not have the same performance as new.
