Procast 2 Pallet Vertical Lathe
ConGri Macchine Utensili sells a Procast 2 Pallet vertical lathe in excellent conditions.
Data sheet
| YEAR | 2003 |
| WORK CAPACITY: | |
| Table diameter | mm. 1.000 |
| Turning Diameter (max) | mm. 1.450 |
| Max. Kg. load on table | Kg. 1.000 |
| Turning Length (max) | mm. 1.000 |
| Spindle speed (max.) | Rpm/1 427 |
| N. of Gear box | N. 2 |
| Power of speendle KW (S1) | Kw. 60 |
| Max. Torque (Nm.) | Nm. 21.500 |
| SLIDE: | |
| RAM Dimension | mm. 250 X 250 |
| X Axis travel | mm.- 800 /1.550 |
| Z Axis travel | mm. 1.000 |
| Torque nominal motor (Nm) | Nm. 27 (X) / 27 (Z) |
| Nominal Thrust force (Nm) | N. 27.100 (X) / 19.260 (Z) |
| Rapid Feedrate | mm.1 15.000 |
| TOOL MAGAZINE: | |
| Number of tools | 60 |
| Tool type | Capto C6 |
| Max wheigt of single tool | Kg. 20 |
| Max Lenght of single tool | mm. 300 |
| CONTROL | SIEMENS 840D |
| DIMENSIONS L P H | mm.8.410 X 4845 x 5.487 |
| WEIGHT | Kg. NA |
| ACCESSORIES INCLUDED | |
| Asse X e asse Z idrostatici, cambio pallets rotomors, n.1 mandrino autocentrante automatico idraulico a 6 griffe dia. mm.1.000, n.1 mandrino autocentrante manuale a tre griffe dia. mm. 1.000. X axis and Z axis are idrostatics, pallet changer 2 positions, n.1 idraulic chuck whit 6 clamps automatic mm. 1.000 diameter, n.1 manual chuck whit 3 clamps mm. 1.000 diameter. |
All technical data are indicative, may be changed without notice and refer to the standard conditions of the new good. The second-hand good may not have the same performance as the new one.
