Victor Taichung A26/130
Victor Taichung A26/130
THE PRODUCT IS NOT AVAILABLE
Victor Taichung A26/130 CNC lathe from 2018 really nice and well maintained with few hours of use.
Technical Datasheet
| YEAR | 2018 |
| DISTANCE BETWEEN SPINDLE NOSE | mm. 1.360 |
| ROTATING DIAMETER (max) | mm. 800 |
| TURNING DIAMETER (max) | mm. 420 |
| MAIN SPINDLE | |
| SPINDLE NOSE (ASA attachment) | Asa A2-8 |
| SPINDLE SPEED (min./max.) | 3.500 RPM |
| POWER OF THE SPINDLE ENGINE (kW) | Electrospindle DDS Kw 15/22 |
| BAR PASSAGE | mm. 75 |
| COUNTERSPINDLE: | |
| SPINDLE NOSE (ASA attachment) | |
| SPINDLE SPEED (min./max.) | |
| POWER OF THE SPINDLE ENGINE (kW) | |
| BAR PASSAGE | |
| NUMBER OF UPPER TURRETS | 1 |
| NUMBER OF LOWER TURRETS | |
| X SLIDE TRAVEL | mm. 210+50 |
| Z SLIDE TRAVEL | mm. 1.300 |
| Y SLIDE TRAVEL | |
| X2 SLIDE TRAVEL | |
| Z2 SLIDE TRAVEL | |
| Y2 SLIDE TRAVEL | |
| X3 SLIDE TRAVEL | |
| Z3 SLIDE TRAVEL | |
| Y3 SLIDE TRAVEL | |
| RAPID FEEDS | 24 m./min. |
| TOOL TURRET (Model) | 12 positions |
| NUMBER OF TOOL POSITIONS: | |
| T1 | 12 |
| T2 | |
| T3 | |
| CONTROL | Fanuc 0i-TF graphic display |
| DIMENSIONS L P H | mm. L 5.493 X P 2.100 X H 1.935 |
| WEIGHT | Kg. 9.000 |
| ACCESSORIES INCLUDED | Hydraulic chuck Autoblock BHD 315 / Chip conveyor / Tailstock with swivel sleeve / Grundfof high-pressure pump 20 BAR with 150 LT. tank / Electric cabinet cooler / Electronic handwheel / Oil skimmer / Static toolholder kit / Fume extractor / Manual presetting / Hydraulic steady rest with independent axle / |
All technical data shown are indicative, may be changed without notice and refer to the standard condition of new goods. Used goods may not have the same performance as new.
