Makino A55e Horizontal Machining Centre
Makino A55e horizontal machining center
Makino A55e horizontal machining center refurbished, really nice.
Technical Datasheet
| YEAR | 2002 |
| X AXIS COURSE | mm. 560 |
| Y AXIS COURSE | mm. 560 |
| Z AXIS COURSE | mm. 560 |
| SPINDLE | HSK 63 |
| SPINDLE SPEED MIN./MAX | rpm. 14.000 |
| SPINDLE POWER IN KW/MAX | 15/18 Kw |
| OVERALL DIMENSIONS - MAXIMUM WORKPIECE | Dia. mm. 700 X H mm. 800 |
| PALLET NUMBER | 2 |
| PALLET DIMENSIONS | mm. 400 X mm. 400 |
| B Axis | Continuous 0.001° |
| MAXIMUM LOAD ALLOWED | Kg. 400 |
| RAPID FEEDS X,Y,Z | mm./min. 40.000 |
| TOOL WAREHOUSE | 60 Positions |
| CONTROL | Fanuc / Makino professional 3 |
| OVERALL SIZE | / |
| WEIGHT | |
| ACCESSORIES | Chip conveyor specific for aluminum / A.P. 40 Bar with self-cleaning filter brand Knoll / Rotary table 4° continuous axis. |
All technical data shown are indicative, may be changed without notice and refer to the standard condition of new goods. Used goods may not have the same performance as new.
